Series 6100 Signal Conditioning, Amplifier, Filter & Analog Output System

Product Overview

Many facilities have updated the A/D hardware and application software yet are still using 20+ year old conditioners, amplifiers and filters. Series 6100, an innovative and modular transducer conditioning system, has unparalleled performance and accuracy. From two to many thousands of channels, high & low bandwidth, Series 6100 conditions and outputs analog signals from nearly any transducer and is fully customizable to fit the needs of any test facility. Pacific has solutions to update legacy Neff, Dynamics, Preston, Ektron and even Pacific Instruments systems.

Signal Conditioning Configuration

Enclosures

Signal Conditioning Enclosures

Series 6100 and 6000 Enclosures are common between the 2 product lines and can accommodate any combination of Series 6100 I/O Modules. Enclosures are available in a variety of sizes and a selection of AC and DC powered versions to meet the needs of laboratory and portable field applications. With USB 2.0 and Ethernet interfaces available, facility integration couldn’t be easier

I/O Modules

Signal Conditioning I/O Modules

I/O modules configure the 6100 to your specific needs. Pacific offers a broad selection of modules providing a high degree of flexibility, accuracy and performance. Series 6100 I/O Modules condition, amplify, filter and output high level signals to external data acquisition systems. Modules are selected according to functional and performance requirements for your application.

Software

Signal Conditioning Software

PI610 is fully configured and ready to use. It provides on screen programming of operating parameters or can download parameters from an Access compatible database file. It includes a window that graphically displays amplifier excitation and output.

Additionally, users can integrate programming functions inside existing application software using an SDK or high-level instruction set.
